Technical parameters:
| Model |
BDF-25V268 |
BDF-25V270 |
BDF-25V328 |
| External Size(W*D*H) mm |
675*675*1580 |
580*600*1750 |
675*675*1850 |
| Capacity |
268L |
270L |
328L |
| Type |
Vertical |
| Temp. Range |
-10℃～-25℃ |
| Temp. Accuracy |
0.1℃ |
1℃ |
0.1℃ |
| Temp. Fluctuation |
±6℃ |
±3℃ |
±6℃ |
| Control System |
Microprocessor Control & LED Display(Except model BDF-25V270 is LCD display) |
| Alarm |
High and low temperature, System &sensor failure, Door ajar, Power failure alarm |
| Refrigeration Type |
Direct Refrigeration |
| Refrigerant |
R404a,CFC Free |
R134a,CFC Free |
R404a,CFC Free |
| Compressor |
International famous compressor |
| Condenser&Evaporator |
High efficiency air-cooled condenser, made of copper |
| Construction |
Structure |
Unibody Design & Mono-assembly foaming (Rigid polyurethane insulation material) |
| Internal material |
Cold-rolled steel coated with anti-bacteria powder for BDF-25V268 and BDF-25V328, ABS material for BDF-25V270
|
| External material |
Cold-rolled steel coated with anti-bacteria powder |
| Shelves/Drawers |
4 shelves |
7 drawers |
4 shelves |
| Consumption |
390W |
130W |
485W |
| Power Supply |
AC220V±10%, 50/60Hz |
| Package size(mm) |
735*755*1635 |
694*651*1830 |
735*735*1900 |
| Gross weight |
125kg |
75kg |
140kg |
|
|
