Features:

Multiple uses
Covering biochemical, cardiac, electrolyte and other instrument functions.
Easy to operate
No training is required and can be operated by non-specialist physicians.
Portable design
The instrument weighs only 4.2Kg, takes up less space, and can be used for medical and community clinics.
Maintenance free
The key components are imported, no internal liquid circuit, pump valve and other wearing parts, two-year warranty, free lifetime maintenance.

Specifications:

Principle Of Detection
Absorption spectroscopy Colorimetric Method, Trans-mission Turbidimetric Method
Analysis Method
Endpoint Method, Rate Method, Two-point Method
Wavelength Range
8 Wavelengths, With Wavelengths of 340,405,450,505,546,600,630, 850 (nm) Respectively
Range of Absorbance
0~2.5A
Measurement Mode
Flow Colorimetric Cell (Stainless Steel Quartz Window, 32 μ l)
Reaction Temperature
25, 30, 37°C, and Room Temperature;
Ten incubation well positions For Optional incubation accuracy 37± 0.1°C
Liquid Absorption Capacity
200~9000ul Adjustable
Light Source
12V/20w, Halogen Lamp with A Life span of over2500 Hours
Human-Computer Interaction
7-inch 800x480 Resolution, Multi-point capacitive Touch Screen
Multi Language Selection
Report Printing
Built In Thermal Printer
Storage
Can store > 3000 Sample Test Results,
> 21000 Quality Control Results
And >2200 Test ltem Parameters
Interface
One Rs232 For program upgrade,
One Ethernet port For Lis connection,
and One USB For upper computer burning
Work Environment
Temperature:10-30°C
Humidity:30%~70%
Power Supply
AC100V~240V,50/60Hz,120VA
Weight
4.2Kg
Size
W250*D300*H135 mm
