| Features:
1. Folding time can be automatically selected, five folds(max): three-horizontal & Two-longitudinal. Folding size(max): 3000x3000mm, can work with various flatwork ironing machine to realize automatic folding.
2. Advanced technology adopted, the folder is equipped with four motors and two frequency converters to improve the folding efficiency, each fold is controlled independently,
3. PLC programmable controller can be rotated within 270°, anti-interference. Perfect man-machine interface, self-diagnostic function and safety system guarantee the easy daily maintenance.
4. Initiate static eliminator to avoid static generation, improve the stability and reliability.
5. Unique folding method for fifth fold, droved by air, protecting the linens and prolong its service life.
Models and Specifications:
| Model |
ZD3000-V |
ZD3300-V |
| Max Folding L×W (mm) |
3000 |
3300 |
| Max Folds |
5 |
5 |
| Folding Speed (m/min) |
50 |
50 |
| Air Pressure (V/Hz) |
AC380/50 |
AC380/50 |
| Motor Power (kw) |
1.3 |
1.3 |
| Compressor Air Pipe Diameter (inch) |
G1/2” |
G1/2” |
| Pressure (Mpa) |
6.5 |
6.5 |
| Dimension (mm) |
4500×2800×1860 |
4800×2800×1860 |
| Net Weight (kg) |
1600 |
1700 |
|
|
