| Characters: |
| 12 pre-determined animal settings ( dog, cat, horse, pig, cow, rabbit, goat ) plus four programmable on request
3-part differentiation of WBC: 19 parameters + 3 histograms
2 sample modes: whole blood and prediluted
Throughput: =2 minute per sample
Up to 35,000 sample results (including histograms) can be stored
Built-in thermal recorder, optional external printer
Auto reverse flush and high voltage burning, clog clearing
Color LCD display |
|
| Specifications: |
PRINCIPLE:
Electrical resistance for counting and SFT method for HGB
SAMPLE VOLUME
Whole blood: 9- 20µ
Prediluted: 20µ
PERFORMANCES:
Parameters Precision CV%
WBC(10 /L) 2.0%
RBC 1.5%
PLT 4.0%
MCV(fL) 0.5%
HGB(g/L) 1.5%
DISPLAY:
Large color LCD, displays all parameters result with histogram of WBC, RBC and PLT
Resolution: 800×600
ALERT:
25 sets of alert message
INPUT/OUTPUT:
RS232, USB, 1 parallel printer, 1 keyboard, mouse
OPERATING ENCIRONMENT:
Temperature: 10-35?
Humidity: =70%
POWER REQUIREMENT:
AC220V, 50Hz
DIMENSION:
273mm (L) ×420mm (W) ×415mm (H)
QUANTITY: 16KG |
|
|
