Features:
--Large door opening for loading&unloading and emote lubricating device low labor fprce requirement during operation and maintenance.
--Micro control LED display, high automation, easy operation, clear program.
--Optional manual or automatic control, the washing period, rinse time and extracting time can be chose.
--suspension structure with hydraulic damper is adopted to realize ultra-low vibration. Frequency converter guarantee the speed adjusted sleeplessly and freely, stable speed transition between washing and high extracting, no basement is required. This washer extractor is widely adopted as first choice by hotel, restaurant, school. laundry center, hospital, etc.
Models and Specifications:
| Model |
XGQ-15F |
XGQ-20F |
XGQ-30F |
| Washing Capacity (kgs) |
15 |
20 |
30 |
| Rolling Container Dimension (mm) |
Ø700×440 |
Ø750×500 |
Ø880×560 |
| Rated Voltage (V) |
220 |
380 |
380 |
| Motor Power (KW) |
1.5 |
2.2 |
4 |
| Frequency Converter Power (KW) |
1.5 |
2.2 |
5.5 |
| Diameter of Hot Water Pipe (inch) |
1.2 |
1.2 |
1.2 |
| Steam Inlet (inch) |
1 |
1 |
1 |
| Diameter of Cold Water Pipe (inch) |
1.2 |
1.2 |
1.2 |
| Steam Pressure (Mpa) |
0.3-0.5 |
0.3-0.5 |
0.3-0.5 |
| Consumes Proportion Of Steam (kg/kg) |
0.9 |
0.9 |
0.9 |
| Air Pressure (Mpa) |
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
| Dimension (mm) |
1050×950×1500 |
1200×1080×1750 |
1400×1380×1720 |
| Total Weight (kgs) |
400 |
500 |
1200 |
| Model |
XGQ-50F |
XGQ-70F |
XGQ-100F |
| Washing Capacity (kgs) |
50 |
70 |
100 |
| Rolling Container Dimension (mm) |
Ø990×670 |
Ø1200×650 |
Ø1200×850 |
| Rated Voltage (V) |
380 |
380 |
380 |
| Motor Power (KW) |
5.5 |
7.5 |
7.5 |
| Frequency Converter Power (KW) |
7.5 |
11 |
11 |
| Diameter of Hot Water Pipe (inch) |
1.5 |
1.5 |
1.5 |
| Steam Inlet (inch) |
1 |
1 |
1 |
| Diameter of Cold Water Pipe (inch) |
1.5 |
1.5 |
1.5 |
| Steam Pressure (Mpa) |
0.3-0.5 |
0.3-0.5 |
0.3-0.5 |
| Consumes Proportion Of Steam (kg/kg) |
0.9 |
0.9 |
0.9 |
| Air Pressure (Mpa) |
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
| Dimension (mm) |
1500×1550×1760 |
1800×1760×2210 |
1850×1950×2250 |
| Total Weight (kgs) |
2000 |
3000 |
3500 |
|
|
